Features - Benefits
1 : Three layers structure cartridge offers excellent dirt holding capacity, longer service life
2 : Graded density pore structure enhances dirt holding capacity
3 : Formed by thermal bond without using any binders and adhesives
4 : Excellent chemical resistance
5 : All end configurations available
6 : Certificated by NSF-42 and FDA CFR Title 21.
Application
- Chemicals
- Paint/Ink
- Water
- Plating
- Pharmaceuticals
- Food and beverages
- Microelectronics
- Cosmetics
| Micron ratings | 1, 3, 5, 10, 25, 50, 75, 100 Micron |
| Material of construction | 100% PP Melt-Blown Micro Fiber |
| Length | 9.87'', 10'', 20'', 30'', 40'' (251mm, 254mm, 508mm, 762mm, 1016mm) |
| Inner diameter | 28mm |
| Outer diameter | 63mm |
| End Cap | Polypropylene |
Ordering Information
| Pei Ting Filter |
OD | Micron Rating | Length | End Cap | O-ring / Gasket |
| Ex : MAP | A | 050 | 20 | P2 | E |
| Multi-Layers PP Depth Filter | A = 63mm | 001 = 1 micron 003 = 3 micron 005 = 5 micron 010 = 10 micron 025 = 25 micron 050 = 50 micron 075 = 75 micron 100 = 100 micron |
987 = 9.87" 10 = 10" 20 = 20" 30 = 30" 40 = 40" |
N = None End Cap DO = Double Open End P2 = 222 / Flat P3 = 222 / Fin P4 = 226 / Flat P5 = 226 / Fin |
E = EPDM N = Buna N V = Viton S = Silicone T = PFA encapsulated Viton A = PE gasket only |
